40 x 80 M12 Stem/Plate Caster Mounting Kit
Product #:
40DCP-0401-001-02
Description:
Profile
- 40X80 6-SLOT HEAVY DUTY / 40P03-001X-000.
- 40X80 3-SLOT 90° STANDADARD DUTY / 40P04-122X-000.
- 50X80 4-SLOT SINGLE FLANGE LIGHT DUTY / 40P03-123X-010
Caster
- M8 STEM MOUNT Ø50mm CASTER W/TOTAL BRAKE (40 KG) / 00DCA-3200-001-00
- M12 STEM MOUNT Ø75 mm CASTER W/TOTAL BRAKE (70 KG) / 00DCA-3300-001-00.
- PLATE MOUNT Ø 75mm FIXED CASTER (70 KG) / 00DCA-3300-002-00
- M12 STEM MOUNT LEVELING CASTER (250 KG) / 00DCA-3500-004-00.
- PLATE MOUNT SWIVEL LEVELING CASTER (250 KG / 00DCA-3500-003-00
- PLATE MOUNT Ø125mm SWIVEL CASTER W/TOTAL BRAKE (125 KG) /00DCA-3400-002-00.
- PLATE MOUNT Ø125mm FIXED CASTER (125 KG) /00DCA-3400-001-00.
| Material | 6061-T6 | |
| Finish | Type II, Class 2 Anodize, Black | |
| Parts Included in Kit |
(1) 40x80 M12 Stem/Plate Caster Mount [40DCP-0401-001-00] (2) M8x1.25x16mm 10.9 SHCS [00HSW-3401-002-00] (2) M8 35mm 1-Hole Std. Offset Nut [40HSN-3507-001-00] |
|
| METRIC | SAE | |
| Weight | 0.30 kg [306 g] | 0.67 lbs [10.8 oz] |
×
